SCH80标准 Size |
Do |
d1 | d2 | I |
d |
J |
L |
1/2" |
29 |
21.54 |
21.23 |
24.22 |
16 |
6.5 |
61 |
3/4" |
35 |
26.87 |
26.57 |
27.4 |
22 |
8 |
71 |
1" |
44 |
33.66 |
33.27 |
30.58 |
28 |
8 |
81 |
1-1/4" |
54 |
42.42 |
42.04 |
34.75 |
35 |
10 |
92.5 |
1-1/2" |
60 |
48.56 |
48.11 |
37.93 |
43 |
12 |
102.5 |
2" |
73 |
60.63 |
60.17 |
41.1 |
54 |
16 |
120 |
2-1/2" |
88 |
73.38 |
72.85 |
47.45 |
65 |
18 |
143 |
3" |
105 |
89.31 |
88.70 |
50.63 |
80 |
19.5 |
58.5 |
4" |
132 |
114.80 |
114.10 |
60.15 |
100 |
26 |
194 |
5" |
1562 |
141.81 |
141.05 |
69.6 |
134 |
38.4 |
243 |
6" |
191 |
169.83 |
168 |
79.2 |
150 |
45 |
280 |
8" |
246 |
219.84 |
218.69 |
104.6 |
200 |
51 |
353 |
10" |
306.5 |
373.81 |
372.67 |
130 |
265 |
60 |
433 |
12" |
364 |
324.61 |
323.47 |
155 |
315 |
73 |
518 |
14" |
397 |
356.49 |
355.22 |
180 |
346 |
150 |
704 |
|
